DTM-22-RTD-TC-STAND
Product Description :
HTM-22 – High Accuracy Industrial Handheld Hygro-Thermometer.
HTM-22-60 – Digital Hygro-Thermometer for industrial use up to max 60°C.
HTM-22-80 – Digital Hygro-Thermometer for industrial use up to max 80°C.
Technical Specifications :
| Parametes | Description |
| T + Rh Sensor / Probe | Hygroclip CP (T+Rh) from Rotronic-Swiss (L=200 mm) with 1-meter extension cable and abonite / PVC handle for strong grip. |
| Temperature Measuring Range | -40.0 to +60.0 °C, -20.0 to 80.0 °C |
| %Rh Measuring Range | 0.0 to 100.0 %Rh |
| Accuracy | ±0.1 °C for temperature and +/-2% for %Rh |
| Resolution | 0.1 °C / %Rh |
| Display | 4 Digit, 0.5" height, 7 segment numeric LCD. |
| Display Scan Rate | Every 5 seconds for T and Rh (Can be paused by the keypress). |
| Soft Touch Key pad | For °C / %Rh / Max / Min / Hold / Clear / Back Lit Functions. |
| Battery | Single 9V dry cell or 9V /100mA adaptor (External). |
| Serial Interface | RS232 port for PC interface with additional adaptor (available as additional accessory). |
| Key Sound | Miniature beeper – sounds on Keypress. |
| Over range indication | Provided. |
| Low Battery indication | Provided. |
| Size | 150 (H) x 82 (W) x 35 (D) mm. |
| Weight | 200 gms approx. |
| Enclosure | ABS Plastic body with polycarbonate front and a membrane keyboard. |
